SR6 Full Suspension Mountain Electric Bike 26×4.0 | 750W BAFANG Motor, 48V 16Ah LG Battery, Long-Range Fat Tire E-bike
Key Highlights
⚡ 48V 750W BAFANG Motor – Powerful motor for hills & off-road riding
🔋 48V 16Ah LG Battery – Long range 50–70km per charge
🏞 Full Suspension – Front hydraulic + rear four-link for smooth ride
🚴 26×4.0” Fat Tires – Extra grip for all terrains
🖥 LCD Display – 5 pedal-assist levels, 48V battery display, waterproof
⚙️ Shimano 8-Speed – Smooth shifting for city & mountain trails
📦 Aluminum Frame – Durable 26” frame, max load 150kg
Request Product List / Ask for OEM Options
Technical Specifications
| Item | Parameter |
|---|---|
| Motor | 48V 750W Brushless Motor |
| Battery | 48V 16Ah Lithium Battery |
| Controller | 25A Intelligent Controller with PAS |
| Display | LCD, 5-Level Assist |
| Frame | 26″ Aluminum Alloy |
| Tires | 26×4.0 Fat Tires |
| Brakes | Hydraulic Disc Brakes (F/R) |
| Transmission System | Shimano 8-Speed |
| Charger | 54.6V 2A UL-certified (Optional) |
| Max Speed | 45km/h (adjustable limiter) |
| Range | 50–70 km (PAS) |
| Load Capacity | 150kg |
| Net Weight | 33.33 kg |
| Gross Weight | 42.22 kg |
| Waterproof Rating | IPX5 |
| Certifications | CE, UL 2849, EN15194 (supported if required) |
| Package Size | Approx. 1670×270×770 mm |
| Minimum Order Quantity | 50 units (customizable) |
| 40HQ | 180 sets |
Note: Specifications may vary slightly based on customization.
Accessories
The SR6 electric mountain bike is powered by a 48V 750W Bafang brushless motor, delivering strong and reliable performance for climbing hills, tackling rough terrain, and conquering off-road adventures.
SR6 features a clear LCD display showing 48V battery, speed, and 5 assist levels.Supports J-protocol with adjustable top speed up to 45 km/h.Waterproof wiring keeps you in control on all terrains.
The 26×4.0 fat tires on the SR6 mountain e-bike provide excellent grip, shock absorption, and stability. Perfect for off-road trails or city streets, they ensure a safe and comfortable ride on any terrain.
Recommended Use
Mountain & Trail Advent
The SR6 electric mountain bike excels on rocky, uneven, or sandy trails, perfect for adventurous outdoor rides.
Recreational Riding
Enjoy relaxed weekend rides with the SR6, offering comfort, control, and reliable long-range performance.
Touring & Commuting
Strong motor and long battery life let the SR6 handle daily commuting and multi-day tours with ease.
Beach & Coastal Riding
Wide fat tires provide stability on sand, making the SR6 mountain e-bike perfect for beach and coastal routes.
Customization & OEM Services
Our streamlined OEM process ensures efficient production and timely delivery. For detailed OEM workflows and cooperation policies, please visit our OEM / ODM page.
Quality Assurance & Certifications
For detailed certification documents and factory information, please visit our Factory & Quality page.
If you have any questions or require a personalized quote, please contact our sales team at easywayebike@gmail.com or WhatsApp +86 135 5499 1036
Frequently Asked Questions
A1: The MOQ is 50 units per model.
A2: Standard lead time is 35-60 days depending on order volume and customization.
A3: We provide a 12-month warranty covering manufacturing defects.
A4: Yes, sample orders are available. Please contact us for pricing and delivery details.
For more FAQs and support, please visit our Support page.
